H121 Broken Bridge Window Screen Integrated External Opening Window

HSTM outward-opening windows utilize a multi-cavity structure, combined with glue injection, to make the overall frame structure more stable than ordinary outward-opening windows. At the same time, they adopt integral built-in Roman crimping and europium aluminum corner codes, which are suitable for different processing habits and processing equipment. HSTM has developed three types of large and small buckles, which can effectively realize the buckle conversion of over-large glass. The glass adopts a middle sealing structure to eliminate the hidden danger of water leakage from the buckle strips and ensure air tightness, heat insulation and sound insulation.

Inquiry

Write a Review

Basic Parameters

Heat resistance performance	Soundproofing performance	Watertight performance	Hurricane performance	Airtight performance
Uw1.7W/m2 K	Rw up to 38dB	720Pa	5200Pa	Ievel 7

Main Profile wall thickness(mm)	Dimensions of Front-view surface(mm)		Frame wall-mounting Size(mm）		Glass thickness (mm)	Insulation Strip(mm)	Window panel
2.2mm	Frame: 28	Glass profile: 80	External frame	120	5G+20A+5G	35.3	W: 400mm-800mm
	Strengthen mullion: 28	Screen Panel: 65	Screen Panel	30			H: 400mm-1600mm
	Adapter frame: 55		Glass panel	55			Weight limit: 60kg

There are three opening methods

Outward Flat-opening

Outward Top-hinge opening

17 Outward Flat-opening and Outward Top-hinge open

Outward Flat-opening and Outward Top-hinge opening

Glass

Screen

Hardware

H121 Broken Bridge Window Screen Integrated External Opening Window 7

H121 Broken Bridge Window Screen Integrated External Opening Window 8

Product Features

● The frame and stem are both rectangular 5-cavity structural designs, with glue-injected corner codes and glue-injected functional connectors, making the connection firm and the frame structure stable.

● It adopts europium aluminum corner code. The corner code has both the corner assembly function of the corner assembly and the corner assembly function of the jack screw. It is suitable for different processing habits and processing equipment. A full range of outdoor EPDM strip sealing designs, and the glass buckles are all on the indoor side, eliminating installation hazards;

● This series of glass fasteners is exclusively developed and designed by our company. It adopts the overall embedded three-dimensional crimping line to achieve the stability of large glass after installation. It is more convenient to install, not easy to scratch, and the overall vision is simple, grand and beautiful. Our company has developed 3 large and small buckles to realize the conversion of extra large glass buckles.

● The middle sealing structure of the sub-frame solves the problem of poor controllability in the installation and construction of the adapter frame and the hidden danger of water leakage in the adapter frame.

● The exterior and interior are coplanar, making the inside and outside of the window sash flush, perfectly hiding the gap between the frame and sash, and making the visual effect more simple and beautiful.

● The outward-opening sash is designed for indoor installation. The outward-opening sash and adapter frame can be installed in one piece and operated indoors to avoid the safety hazards of on-site installation of outward-opening sash.

● The fixed glass adopts an intermediate sealing structure to eliminate the hidden danger of water leakage from the buckle strips, and simultaneously improves air tightness, thermal insulation, and sound insulation.

● The screen fan's anti-collision and corner protection technology solves the problem of sharp corners, making the design safer and preventing accidental scratches. It is a more humane modern home design.

● The open drainage function design, combined with the external windshield drainage cover, avoids the phenomenon of water backflow and makes drainage smoother.

● There are various styles of guardrails, including fixed guardrails and fixed minimalist guardrails.

Product details

Product details1

HSTM outward-opening windows adopt integral built-in Roman press lines. This method originated from the appearance design of Italian Roman columns. The overall appearance is visually generous, grand, and European style. The press lines are flat on the appearance and are not easy to scratch.

Product details2

HSTM outward-opening windows have four opening methods: fixed/outward-opening/outward-opening top-hanging/outward-opening top-hanging

Accessories Details

Accessories Details1

The tempered insulating glass used in HSTM outward-opening windows comes standard with 5G+20A+5G insulating tempered glass. In addition, it can be customized according to needs, and can be upgraded to 10G+20A+10G.

Accessories Details2

HSTM outward-opening window hardware is equipped with German Weibichi VBH handle + VBH-90 degree inward opening and inward-turning kit. It can also be equipped with HSTM customized system hardware. It is also available in silver/black.

FAQ

What is the integrated external opening window with broken bridge screen?

The integrated outward-opening window with broken bridge screen is a design that integrates the heat-breaking bridge aluminum alloy window, window screen and outward-opening window. While maintaining thermal insulation properties, such windows also facilitate ventilation and ventilation, and prevent insects from entering the room through window screens. Overall, this design takes into account the needs of thermal insulation, ventilation and insect protection, improving the practicality of the windows.

In what scenarios is the broken bridge window screen external opening window suitable?

HSTM outward-opening windows are made of tempered hollow double white glass, which is flush with the interior and exterior, perfectly hiding the gap between the frame and sash, and achieving a beautiful appearance. It is suitable for places that have requirements for the appearance of the building. Its good heat insulation, air tightness and insect-proof functions of window screens make it suitable for all types of living environments, including houses, apartments, villas, etc.

What are the advantages of external opening windows with integrated broken bridge screen?

HSTM outward-opening windows come standard with 5G+20A+5G insulated tempered glass, and you can customize it according to your personal needs, up to a maximum upgrade of 10G+20A+10G. The entire window uses imported ERDM automotive-grade composite sealing strips and medical stainless steel diamond gauze, and can be customized with a variety of protective fences.

What are the colors of outward-opening windows?

There are various colors such as sand gold black, black gold stone, sand grain gray, sand grain coffee, titanium empty gray, golden teak, etc. At the same time, you can customize it according to your personal needs. For details, you can communicate with us through the HSTM contact information.
