H150 Broken Bridge Intelligent Lift Window

HSTM smart lift window is made of broken bridge 6063-T6 aluminum. Users can remotely control the opening and closing status of the window through the remote control or smartphone application and automatically open or close at a specific time. It has an intelligent infrared sensing system and can Function configuration board, remote control, mobile APP, AI voice function and other intelligent controls can effectively manage indoor temperature.

Inquiry

Write a Review

Basic Parameters

Heat resistance performance	Soundproofing performance	Watertight performance	Hurricane performance	Airtight performance
Uw1.7W/m2 K	Rw up to 30dB	720Pa	5000Pa	Ievel 7

Main Profile wall thickness(mm)	Dimensions of Front-view surface(mm)		Frame wall-mounting Size(mm）		Glass thickness (mm)	Insulation Strip(mm)	Window panel
2.0-3.3mm	Frame: 120	Glass profile: 50	External frame	165	6G+20A+6G	14.8	W: 1000mm-5000mm
			Screen Panel	64			H: 800mm-1500mm
			Glass panel	103			Weight limit: 250kg

opening methods:

Electric Lifting

Glass

Screen

H150 Broken Bridge Intelligent Lift Window 4

H150 Broken Bridge Intelligent Lift Window 5

Product Features

● Armrest surface width 14.5 cm

● When closed, an ultra-wide wind pressure-resistant cross-section is formed

● Standard glass configuration: 6G white glass +20A+6G white glass insulated tempered glass

● The fixed sash position can be matched with smart lift screens

● Adopting broken bridge insulation system to maintain indoor temperature and excellent sound insulation effect

● Equipped with function control panel, remote control, mobile phone APP, and A voice control system

● Optional backup battery makes our life more worry-free

Product details

Product details1

The multi-cavity structure design of the profile can reduce heat loss caused by air convection, achieve good thermal insulation performance, and can also isolate the transmission of sound.

Product details2

The HSTM lifting window armrest has a surface width of 14.5CM, which can provide stronger support and reduce the risk of users falling or losing balance when using the window. This is especially important for families with young children or older adults at home.

Accessories Details

Accessories Details1

HSTM lift windows come standard with 6G+20A+6G extra-large medium-sized blank glass, filled with inert gas (xenon), which effectively reduces heat loss from door and window glass, blocks noise, and achieves excellent noise reduction, heat preservation, and sound insulation performance.

Accessories Details2

P66 high performance thermal insulation strip 25mm multi-cavity automotive grade EPDM sealing strip plays a vital role in sound insulation, waterproofing, weather resistance and heat insulation.

FAQ

Can screens be installed on lift windows?

Screen windows can be installed at the fixed sash position, and the screen window style can also be customized through the HSTM contact information.

Are lifting windows safe during use?

It can be equipped with fixed guardrails. The lift window is equipped with an intelligent infrared sensor system. When a foreign object blocks the infrared rays, it will automatically stop lifting to prevent hands from being pinched.

What are the control methods for lifting windows?

Form configuration function control panel, which can also be remotely controlled through mobile APP, remote control, and AI voice function
